A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 68

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 68
ng up, stillthey will help to show the position of the ribbandsas they are bent around the frames. Filling-in Pieces.—The fiUing-in pieces, usually2 wider than the top of the keel, are placed in thespaces between the frames, level with the floor tim-bers. They are fastened to the keel and form… … 66 COURSE IN WOODEN BOAT AND SHIP BUILDING
