Hatton, Richard G · London, Chapman & Hall ld. · leaf 144
Fig. 71.—The eye in relation to a verticalplane perpendicular to the pictore. Eye … Fig, 72.—The eye in relation to the V.L. of avertical plane at an angle to the pictnre, andshown also laid down into the picture-plane. Fig. 73.—The facte of Fig. 72shown as they appear onthe paper when working. no Perspective and will thus give a wider measurement than formerly.Hence it is…
Perspective · Drawing
