re the sloping plane cuts through orintersects the horizontal one. Finding Picture-lines 115 41. Finding Picture^Iincs. Picture-lines are the Lnes made where planes comingforward from distant vanishing lines strike the picture-plane. It should be noted at the outset that if theplanes be… … Fig. 78.—Picture-lines declaring (1) and not declaring (2) the distancebetween two planes. it, then the distance between their picture-lines will begreater than the distance between the planes themselves,as No. 2, Fig. 78. The former case will apply to thoseplanes which have their V.L.s through the…
