left. Hence, thebase of a cube being foundin the plane, the up-right edges of the cubewill vanish to the V.P.on the right. These up-right lines are in hori-zontal planes vanishingon to the horizon. ToFig. 98.—A cube of 7 feet in a vertical measure the lines, we drawplane perpendicular to the…
