, occurring where the V.P- of thedirection of the inclination was found. It was throughthis V.P. that the vertical V.L. was drawn. Of thisV.L., C.V.L. is the centre. Eye 2 is the position of the eye in relation to thisvertical V.L., and eye 2 gave us the inclination ofA.V.P. upward (that of the… … Tto. 100 —A cube with base in a vertical plane at 18° to the left.
