Hatton, Richard G · London, Chapman & Hall ld. · leaf 41
Fm. 5. —The image, B, produced on the picture-plane by rays inter-secting the plane. the student should understand this, for it is somewhatstartling to have to accept a point on the picture-plane, … Fig 6.—The artist touching a point some miles away. perhaps not above 12 feet from one, as actually apoint miles in the distance. But of course, to thespectator, if a point on the picture-plane Nicies the point The Picture-plane 7 in the far distance, it is that point, for it takes its placein the…
Perspective · Drawing
