Hatton, Richard G · London, Chapman & Hall ld. · leaf 93
decidedupon. Of course, whether the scale be 1 or ^ to thefoot, or more or less, will make no difference except inthe size of the drawing. 58 Perspective 21. The Theory of the Horizon and of VanishingLines and Points generally. We did not find the horizon by any method, but drewit across the paper… … Fig. 37.—The theory of finding the horizon. object, picture-plane, and eye, as in A, Fig. 37. We drawfrom the eye a line parallel to the plane whose V.L. werequire. The plane is the ground-plane on which thehouse stands. We draw the line P.V.E. parallel to theground-plane, and so obtain the point…
Perspective · Drawing
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
