Applied perspective, for architects and painters (1901)
Longfellow, William Pitt Preble, 1836-1913 · Boston and New York, Houghton, Mifflin and company · leaf 176
ch it cuts the lines j-j,3-3 will be points in both main vault and lunette vault, and therefore in their intersec-tion, the groin. The other pairs of points, i-i, 2-2, etc. may be found by the sameprocess, and the line of the groin drawn through them. The entablature from whichthe vault springs is… … Wqt &toemt>e Ijptzm CAMBRIDGE ■ MASSACHUSETTSU • S ■ A
Perspective
