Trace Vertical Plane la THE PERSPECTIVE DIAGRAM. may be upon the same plane (as a sheet of paper) as the picture line,the trace of the vertical plane, and the station point. •■ The point directly opposite the eye on the vertical plane in thehorizon is called the center of vision, seen in Fig. 2, at…
