approximately 1,000 meters with the Stdbi connection, onlythe billi condenser is employed in shunt to the secondary winding, but for longer wavelengths the small six-point, double throw switch, mounted on the top of the tuner (markedchange-over switch in Fig. 164), is placed in the Stdbi long wave… … 148 PRACT-ICAL WIRELESS TELEGRAPHY. The complete circuit for this connection is indicated in Fig. 16Sa. Note carefully thatthe intermediate circuit is not employed. It is important to note also that the type 107-atuner is fitted with four binding posts (at the rear) from which connections extend to…
