e of pneumatic tools this work is very simple and the classof work as far as rivet holes is concerned, is all that can be desired. STEEL SHIP CONSTRUCTION 135 RIVETING As explained in the previous article all the work is bolted up andthe holes examined prior to the riveters starting work.… … Fig. ISO. Fig. 155 shows the style of rivets used and formed throughouton lake-built vessels. , A, B, C and D show ^, }i, % inches and one inch diameter rivetswith the countersunk points and pan heads, the points are left slightlyconcave as shown by sketches and termed full rivets. E, F, G and H…
