Fig. 176. 164 LAKE SHIP YARD METHODS OF plate will measure three and three-quarters inches at end of straightline where the curve of bilge commences, shown by Fig. 179. In thisway the bottom is tested as regards the rise oi floor. Very little trouble is experienced ■ in fetching the - bottom to… … . Fig. 182. Fig. 183. prior to erecting and when fastened to the center keelson pulls, theshell plating in place if it should be nearer a straight line than therise designed. When the plating is put upon the bottom the straight edge will beused every hundred feet so that the plating will require…
