/T^ 9 side shell plate the mold ispacked out with pieces ofwood the thickness of the in-side bilge plates, d, Fig.15. This method of making anallowance for the outsidebilge plate facilitates the ar-rangement of rivet holesaround the bilge and keeps auniform pitch throughoutthe vessel. This mold…
