hine is carried upon strong butiiexible steel springs. The steam-pressure is usually morethan 100 pounds. The puUing-power is generally about one-fifth the weight under most favorable conditions, and be-comes as low as one-tenth on wet rails. The fuel employedis wood in new countries, coke in… … FiG. 12T.—British Ejtpresa Engine. ish express-engine, 0 is the boiler, N the fire-box, X thegrate, G the smoke-box, and P the chimney. /S is a springand R a lever safety-valve, T is the whistle, Z, the throttleor regulator valve, E the steam-cylinder, and W the driv-ing-wheel. The force-pump, B C,…
