heymay be easily fastened together and make a strong boxafter being so fastened together. Perhaps the best way will be to construct it like Fig. 100.This gives us a square centre piece as large as can be madeconveniently, then there is a good flange on each branch.By means of screws through these… … FlG. 100. makers are too apt to let a job develop itself, and manya botch has been made in this way. A Httle forethoughtwould generally prevent this, but the lack of it keepsmany otherwise good mechanics down at the bottom of theladder. The first thing in order will be to find out how large wemust…
