Ballard, William Cyrus, Jr · New York [etc.] McGraw-Hill company, inc. · leaf 61
smoothout the variations. Coil Li is shunted by another condenserC2, and the two values are adjusted so that they are resonanttogether at the supply frequency. This, as can be math-matically shown, produces a very high resistance to thepassage of currents of this particular frequency and is an 38… … Fig. 19.—Hot cathode or Kenotron rectifier,ampere at 100,000 volts. Normal rating 0.1 eliminate all of the distm-bing variation. If it is desiredto smooth out the wave stiU further, other sections of seriesinductance and shunt capacity may be added with increas-ingly better results. With properly…
Radio
