Fig. ao8. 208 Voltaic Electricity of the second by binding-screws m (fig. 209), the zinc of thesecond to the copper, &c., of the third, a battery is formed ; theterminals are joined to the zinc and copper of the end cells by … Fig. 209. binding-screws, a b. Joining cells in this manner, is calledjoiningin series. Fig. 210 is the form of Daniells battery
