Hobart, H. M. (Henry Metcalf), 1868-1946 ed · Philadelphia, J. B. Lippincott · leaf 237
Fig. 1 Fig. 2 Kg. s Various Equaliser Switch Connections Pig-4 winding before the machine is connected tothe live bus-bars, as otherwise the rush ofcurrent through the series winding wouldalter the voltage of the machines at the in-stant they were paralleled. The equalisingswitch is therefore…
Electrical engineering
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
