Hobart, H. M. (Henry Metcalf), 1868-1946 ed · Philadelphia, J. B. Lippincott · leaf 358
Cr M Ct APPARATUS FOR POULSEN SYSTEM OF WIRELESS TELEGRAPHYAND TELEPHONY n, Aerial Wire ; cb, Receiving Condensers ; Ci, Transmitting Condensers ; c, Arc Geneiator;L, Inductances: m. Microphones VIofacep. 62S. Wireless Telegraphy — Wireless Telephony 629 coupled, either inductively or… … Fig. 9.—Diagram of Transmitting Connections in tlieLepel System A, Aerial wire. G, Generator. Ci, C2, Capacities. Iq, L2,Coupled inductances. L3, Aerial inductance. Si, Sj, Supplyterminals. E, Earth. The current in Oi, L,, Q lias usuallythe same frequency as A, Lj, Lj, Q, E. receiver has three…
Electrical engineering
