at the second office through arelay at the second office to ground at the fir«t office. As the plughas not been inserted into the jack at the second office the attrac-tion of the armature of this relay will cause the lighting of thelamp at that office. When the operator at the second office… … FIG. 313.—CONNECTION BETWEEN PRIVATE-BRANCH EXCHANGE ANDCITY SUBSCRIBERS WHEREIN THE PRIVATE-BRANCH SUBSCRIBERCONTROLS THE SUPERVISORY SIGNALS AT THE PRIVATE-BRANCHBOARD. 415 416 AMERICAN TELEPHONE PRACTICE. rent over the line will cause the going out of the lamp at the firstoffice. It is evident…
