ng thetip strand terminal to the plug end, as shown in Fig. 370, but in thiscase the metal terminal is fork-shaped and is squeezed tightlyaround the wrapping of wire on the outside braid of the cord. 524 AMERICAN TELEPHONE PRACTICE. The tinsel projects through this and is soldered to the terminal,… … FIG. 372.—RACK END OF CORD. be hooked on to the cord-connecting rack to form a support forthe cord, which will relieve the conductors from strain due to thecord weights. The method of connecting the cord to the connecting rack isshown in Fig. 373, which shows two stationary terminals secured tothe…
