sider first the action ofa link carrying one memberof each of two turning pairsand acted on by no forces,except such as are transmit-ted by these turning pairs. To fix our ideas, considerlink a of the machine illus-trated in Fig. 107 as the linkcarrying one element (say the bearings) of each of… … Fig. 107 152 APPLIED STATICS force transmitted from link d to link a thru the turningpair I must have its line of action tangent to the frictioncircle of the turning pair at i. This friction circle (dottedin Fig. 107) has been much enlarged for the sake of clear-ness; its radius should equal the…
