i,en they can no longer work perfectly. Foran oscillating bearing,—that is, one that goes back-ward and forward, instead of continually around,—1have found rollers very good, since they cannot getmuch out of line; even when the bearing is a littleimperfect, the rollers cannot multiply the… … Roller construction. The above cut shows a bearing and the constructionlines that must be followed in its manufacture. Thetaper of the axle, roller, and box must all meet in apoint, as at a; this arrangement is evident. Theroller must be kept in proper position and roll aroundthe large end in the…
