e deflection with about two amperes inthe current coils. The normal capacity of the instrument is1.5 kilowatts, or 10 amperes at 150 volts, as shown on theupper scale. A voltmeter of the direct-deflection electrodynamometertype is shown in Fig. 35, showing the construction of the instru-ment made… … Fig. 36. Movable Eleniont inKey.stone Voltmeter 326 ELECTRICAL MEASUREMENTS 31 ELECTROMETERS Principle of Action. Electrometers depend upon the attractionbetween electrostatic charges of opposite signs. Two metallicplates, connected to a source of potential, will take charges propor-tional to the…
