Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 433
nergy passing through thecircuit is accomplished by a revolution counter, usually calibratedin kilowatt hours, the unit which has become almost universallyadopted for the commercial measurement of energy. A diagram of a commutator type of watt-hour meter, showingclearly its essential elements, is… … Fig. 90. Thomson Type C-6 Watt-Hour MeterCourtesy of General Electric Company into a circuit are circular and are placed, one on either side of thearmature, as near each other as possible in order to prevent mag-netic leakage. The number of turns and the size of wire employedvary with the capacity…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
