Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 458
feed wires 413 116 ELECTRICAL MEASUREMENTS from the source of energy, and also the service and load wires forthe watt-hour meters. The use of meter outlet fittings facilitates the work of installingand greatly improves the general character of the installation wherea number of meters are to be… … LOflJJ LOftD Fig. 109. Connections to Side Terminal Two- Fig. 110. Connections to Side Terminal Three-Wire Thomson Watt-Hour Meters. Wire Thomson Watt-Hour Meter.Capacity 5 to 50 Amperes Capacity 5 to 50 Amperes nating-current meters and not less than 15 inches for direct-currentmeters. Diagrams of…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
