t passes through a little chamberC filled with granular carbon to the conducting back d of the trans-mitter, and thence through the primary p of the induction coil, andback to the battery. As the diaphragm vibrates it varies the pressureupon the many contact points of the granular carbon through… … Fig. 78. Sectional View of Modern Telephone Receiver. Receiver t Transfnitter Receiver
