Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 387

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 387
Fig. 126. AUis-Chalmers 2-Layer Winding … Fig. 127. Rotor of a 5625 K. V. A. Allis-Chalmers Turbogenerator is attained by having them project beyond the ends of the core. Atthis point they are firmly held by means of nickel-steel rings. Forthe purpose of obtaining proper ventilation and for muffiing the 347 102 TYPES OF GENERATORS AND…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
