are well insulated from the neigh-boring metal and securely held in position by the pole shoes. Theexciting current is fed into the field winding through carbon brushesand cast-iron collector rings. These rings are supported on a cast-iron hub from which they are suitably insulated. In the… … Fig. 130. 2000 K. ^. A. Coupled-Type AlternatorCourtesy of Crocker-Wheeler Company are mounted on the bearing or bearing bracket. All bearings arering-oiling, with caps that are easily taken off to permit the removalof the journal boxes. In the larger sizes the stator frame and bear-ing pedestals…
