o133 in sizes from gV to | h. p. and operating on 100 to 115 volts. 192 TYPES OF GENERATORS AND MOTORS 147 These same designs do for fan motors, small power motors, and fordriving exhaust fans. These motors, the general appearance ofwhich is shown by Fig. 190, are made in two styles, clutch and… … Fig. 191. 50 H. P. Form K Induction Motor Courtesy of General Electric Company to the main field or stator winding of the motor, and connected inmultiple with the main winding, is an auxiliary or starting windingplaced midway between each main coil. The machines, therefore,are split-phase while…
