Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 69

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 69
on shown in Fig.57, which is the resultant flux dis-tribution around the armature whenthe machine is under load. Themagnetism is distorted in the direc-tion of rotation, as if the armaturetended to draw after it the flux issu-ing from the field-poles. But this is not the physical fact, because itis… … Fig. 57. Normal Flux Distribution inDynamo

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
