Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 96

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 96
ficient ofdispersion not only varies with different typesof machine, but is not generally constant evenin a given machine, since it rises with theexcitation. Moreover, when a large armaturecurrent flows, the demagnetizing action of thelatter directly aids dispersion, as it usuallyproduces an m. m.… … Fig. 96. Magnetic Leakage or Stray Flux in Bipolar Field

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
