machines are operatedin series in order to obtain the high voltages now common in heavytraction service. No special connection is necessary in the machine itself to 142 MANAGEMENT OF DYNAMO-ELECTRIC MACHINERY 21 connect it in series with another. The negative of one machine issimply connected to… … Fig. 12. Westinghouse Type Q Generator Showing Commutating Poles tating-pole type of generator. This differs from the above, inmechanical respect, only in the fact that midway between eachpair of main poles there is a small pole. The electrical connec-tions differ from those of the…
