An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 205
Fig. 56. Exploded View of Century Electric Split-Phase Induction Motor Starting. In starting, the rotor revolves freely on theshaft until approximately 75 per cent of the normal speed is £X TEENAL CON NEC TIONS IN TERNRL CON NEC TIOH %^S_E_RIE_S^RES. [iC:^ L/NE … Pig. 57. Connections of Single-Phase Induction Motor with No-Voltage Release Starting Bex reached; the load is then picked up by the automatic action of acentrifugal clutch. The motor is started by means of a starting boxcontaining resistance and reactance. 182 MANAGEMENT OF DYNAMO-ELECTRIC…
