of all kinds—induction typeas well as Thomson meters. Calculations of Customers Bills. The consumption of energyin watt hours being known, the exact amount of the bill can atonce be read from a price chart, one of which is shown in Fig. 100.Dollars and cents are read from the vertical line at the… … Fig. 101. High Potential Testing Transformerof the General Electric Company vertical line marked 28 to its intersection with the diagonal linemarked 12^ cents. From the intersection of these two lines, followthe horizontal line to the left, and find $3.50, which is the amountof the bill for 28,000…
