the phaseconstant of the winding. When the winding is concentrated, the factor K is called theform factor of the electromotive force curve. This factor A^ dependsin general upon the manner in which the magnetic flux is distributed 110 ALTERNATING-CURRENT MACHINERY 99 in the air gap, and upon the… … rig. 103. Ideal Distribution ofMagnetic Flux Fig. 104. Armature Winding Diagram,Four Slots per Pole in practice—when the magnetic flux-density—that is, the fieldintensity in the gap space between the pole faces and the iron of thearmature core— is zero at the points a, Fig. 103, and when this…
