Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 151
owards thereader (that is, from backto front) in slot a2; thenfrom front to back in a^,from back to front in 04,and so on. The variousconductors in slots cti, a2,03, etc., are joined in seriesby connectors (at front andback), and the two ends ofthe final series are connected to two collector rings.… … Fig. 120. Distributed or Multi-Coil Windingfor Two-Pha^e Alternator 132 ALTERNATING-CURRENT MACHINERY 121 B mam 3 ma/n g Diagram of Collector Ring Sjstemfor Two-Phase Alternator SO on. The various conductors in slots 61, 62, &3, etc., are joined inseries, and the two ends of the final series…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
