above thewheel pit. The shafts arekeyed to the rotor and are arranged for coupling to the water-wheel shaft. The style of bearings adopted depends upon the size of thealternator. Some of the smaller machines are furnished with endshield bearings but the standard form for horizontal shaft… … Fig. 174. Completed Field Coil for Rotor of Fig. 172 177 166 ALTERNATING-CURRENT MACHINERY below the bearing through which the cooHng water is conducted,thereby reducing the temperature of the oil. Vertical shaft alternators are arranged for direct connection tothe water-wheel shaft and are usually…
