ALTERNATING-CURRENT MACHINERY 175 Curtis Turbo-Alternator. A general view of a Curtis steam tur-bine alternator, built by the General Electric Company, is shownin Fig. 183. This unit is rated at 5,000 kilowatts, 13,000 volts,25 cycles, and 750 revolutions per minute. As is usual with… … Fig. 184. Two Views of Stationary Armature of Curtis Alternator are below. The stationary armature with the clamping devices forrigidly supporting the coils is shown in Fig. 184. Fig. 185 is a view of a smooth core rotor for a 9,000-kilowattvertical type of Curtis turbo-alternator. A feature of…
