Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 321

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 321
shell. There has been much discus-sion as to the relative merits ofthe shell and core types, some manufacturers going so far as to claimexclusive advantages for one or the other. The fact is that no gen-eral conclusion can be drawn as to which type is better, for eachpossesses inherent… … Fig. 237. Core-Type of TransformerAssembled with Case Removed 284 ALTERNATING-CURRENT MACHINERY 271

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
