Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 328
Fig. 247. Specimen Coils for General Electric Core-Type Transformer nals are shown connected to a terminal board in front, and thefour secondary terminals, two for each coil, arc shown in the rear. 290 ALTERNATING-CURRENT MACHINERY 277 These remek-type transformers are wound for a primaryvoltage of… … Fig. 24S. General Electric Core-Type TransformerCompletely Assembled Showing Deep Corruga-tions to Facilitate Cooling transrormer removed from its tank. It is called the diMrihutedcore type (type H form K) by its makers, the General Electric Com-pany, although it resembles the shell rather than the…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
