Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 333
Fig. 257. Assembled Coils for Westinghouse Transformer 295 282 ALTERNATING-CURRENT MACHINERY Another exam])le of the combined shell- and core-type of trans-former is the distributing transformer (types S and SA) of the West- … Fig. 258. Section through Westing-house Type S Transformer
