Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 334
Fig. 261. Pancake CoilWound with Tape inghouse Electric Company. These transformers are almost iden-tical in form and design with the type H form K transformersjust described. 296 ALTERNATING-CURRENT MACHINERY 283 … Fig. 262. Pancake CoilShowing Use of Insu-lated Flat Strips Fig. 256 shows the core and coils and terminals of the typeS transformers removed from the case, and a general view of thecase. Fig. 257 shows the appearance of theassembled coils and leads of 10- and 15-kw.transformers, with the…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
