e the trans-former is in operation. The core and the coils are first assembledafter which they are tightly clamped and suspended from the cover 301 288 ALTERNATING-CURRENT MACHINERY by means of heavy bolts, as shown m Figo 2C9. The completed trans-former filled with oil may be easily lifted and… … Fig. 260. General Electric Shell-Type Water-Cooled Transformer—Tank Removed and Cooling Coils Shown in Section therefore, are not interfered with when the transformer is removedfrom its tank, (b) The terminal board at the top is accessiblethrough openings in the cover and changes in electrical…
