Current, and Power Curves for anAlternator in a Circuit Containing Inductance In Fig. 17 the full-line curve represents the electromotiveforce of an alternator and the heavy-dotted curve represents thecurrent delivered by the alternator to a receiving circuit having 25 16 ALTERNATING-CURRENT… … Fig. 18. E. M. F., Current, and Power Curves for Alternating Circuit withLarge Inductance positive and negative values; the alternator does work on the cir-cuit when ei is positive, or is above the horizontal axis of time; andthe circuit returns power to the alternator when ei is negative, oris…
