Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 375
the transformer whose current is to beconverted into direct current to the positive plate (iron) of the celland the negative plate (aluminum) to the positive terminal of thestorage battery to be charged. To complete the series circuit thenegative terminal of the storage battery is connected to the… … Fig. 291. Diagram of Connections for Aluminum Valve Rectifier plate (the negative) are immersed, constitutes the rectifier. Withsuch a single cell only one-half of the complete alternating-currentwave is utilized, the other half of the current wave of reversed signbeing suppressed by the aluminum…
Electrical engineering
