Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 437
urrent in the A conductors has de-creased to the same value, sothat equal currents flow in theA and in the B conductors. Thepoints N and S have moved overone-sixteenth of the circumfer-ence of the stator ring, from thepositions they occupied in Fig.333. Fig. 335 shows the state ofaffairs, after… … Fig. 336. Complete Connections for Four Poles of One Circuit of Three-Phase Induction Motor 392 ALTERNATING-CURRENT MACHINERY 375 of the circumference of the stator ring. This motion of the pointsN and S is continuous, and these points make one complete revolu-tion (in a four-pole motor) during two…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
