Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 445
Fig. 341. Westinghouse Induction Motor Com-pletely Assembled 399 382 ALTERNATING-CURRENT MACHINERY ing and running conditions determine which type to adopt in anygiven case. These types are shown in Figs. 342, 343, and 344. … Fig. 342. Squirrel-Cage Type of Rotor Fig. 342 is a squirrel-cage rotor. Fig. 343 is a rotor woundwith insulated wire, forming what is called a definite*, or ijolar,winding. The terminals of this winding are connected to a start-ing resistance mounted inside of the rotor. A switch is arranged…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
