nsformed by the regulator, and only one-seventh of one per cent of the total power delivered to the feeders. Voltmeter Compensator. The voltmeter compensator is a deviceby means of which the voltmeter on the switchboard in a station ismade to indicate the voltage between the transmission lines at… … Figs. 396 and 397. Vector Diagrams Showing E.M.F.Relations in the Line and in the Compensator tween its terminals. This current is transmitted over a line of whichthe resistance is R (including r) and the reactance is X (including 468 ALTERNATING-CURRENT MACHINERY 451 x), and the voltage at the…
