GROUND GROUND Fig. 73. Connecting Circuits for an Electro-static Ground Detector use of one or two thin vanes of soft iron mounted on a pivoted staffwithin the coil. The soft-iron type of Instrument is calibrated by the use ofdirect electromotive forces or currents, but it does not… … Fig. 74. General Electric Ground Detectorwith Cover Removed currents. A soft-iron type meter (ammeter or voltmeter) shouldbe calibrated, using alternating current of the same frequency as 78 ALTERNATING-CURRENT MACHINERY 69 that for which the meter is afterwards to be used, and of the samewave…
